AMD has released a new graphics driver for Windows 10 and Windows 7/8 users. Adrenalin 19.9.1 comes with support and optimizations for Gears 5 and brings Vulkan 1.1.119 support.
Radeon Software Adrenalin 2019 Edition 19.9.1 Highlights
Support For
– Gears 5
Up to 8% performance improvement in Gears of War 5 running DirectX® 12 on Radeon Software Adrenalin 2019 Edition version 19.9.1 vs. 19.8.2.RS-310Added Vulkan Support
– VK_AMD_device_coherent_memory
This extension adds device coherent and device uncached memory types. Device coherent and uncached memory are expected to have lower performance for general access than non-device coherent memory but can be useful in certain scenarios particularly so for debugging.– VK_EXT_calibrated_timestamps
This extension provides an interface to query calibrated timestamps obtained quasi simultaneously from two time domains such as host and device time domains.– VK_EXT_line_rasterization
This extension adds some line rasterization features that are commonly used in CAD applications and that are supported in other APIs like OpenGL. These features include Bresenham-style line rasterization, smooth rectangular lines (coverage to alpha) and stippled lines for all three line rasterization modes.– VK_EXT_shader_demote_to_helper_invocation
This extension adds Vulkan support for the SPV_EXT_demote_to_helper_invocation SPIR-V extension. The SPIR-V extension provides a new instruction that allows shaders to “demote” a fragment shader invocation to behave like a helper invocation for its duration. The demoted invocation will have no further side effects and will not output to the framebuffer but remains active and can participate in computing derivatives and in subgroup operations. This is a better match for the “discard” instruction in HLSL.Fixed Issues
– Launching RGB Fusion 2.0 may cause a system hang on Radeon RX 5700 series graphics products system configurations.
Radeon Adrenalin Downloads
Quick driver information
OpenGL support
This driver exposes OpenGL 4.6 and 326 extensions for a Radeon RX Vega 56.
- GL_VENDOR: ATI Technologies Inc. - GL_RENDERER: Radeon RX Vega - GL_VERSION: 4.6.13571 Compatibility Profile/Debug Context 19.9.1 26.20.13001.50005 - GL_SHADING_LANGUAGE_VERSION: 4.60 - OpenGL Extensions: 326 extensions (GL=302 and WGL=24) - GL_AMDX_debug_output - GL_AMD_blend_minmax_factor - GL_AMD_conservative_depth - GL_AMD_debug_output - GL_AMD_depth_clamp_separate - GL_AMD_draw_buffers_blend - GL_AMD_framebuffer_sample_positions - GL_AMD_gcn_shader - GL_AMD_gpu_shader_half_float - GL_AMD_gpu_shader_half_float_fetch - GL_AMD_gpu_shader_int16 - GL_AMD_gpu_shader_int64 - GL_AMD_interleaved_elements - GL_AMD_multi_draw_indirect - GL_AMD_name_gen_delete - GL_AMD_occlusion_query_event - GL_AMD_performance_monitor - GL_AMD_pinned_memory - GL_AMD_query_buffer_object - GL_AMD_sample_positions - GL_AMD_seamless_cubemap_per_texture - GL_AMD_shader_atomic_counter_ops - GL_AMD_shader_stencil_export - GL_AMD_shader_stencil_value_export - GL_AMD_shader_trace - GL_AMD_shader_trinary_minmax - GL_AMD_sparse_texture - GL_AMD_sparse_texture_pool - GL_AMD_stencil_operation_extended - GL_AMD_texture_cube_map_array - GL_AMD_texture_texture4 - GL_AMD_transform_feedback3_lines_triangles - GL_AMD_transform_feedback4 - GL_AMD_vertex_shader_layer - GL_AMD_vertex_shader_viewport_index - GL_ARB_ES2_compatibility - GL_ARB_ES3_1_compatibility - GL_ARB_ES3_compatibility - GL_ARB_arrays_of_arrays - GL_ARB_base_instance - GL_ARB_bindless_texture - GL_ARB_blend_func_extended - GL_ARB_buffer_storage - GL_ARB_clear_buffer_object - GL_ARB_clear_texture - GL_ARB_clip_control - GL_ARB_color_buffer_float - GL_ARB_compatibility - GL_ARB_compressed_texture_pixel_storage - GL_ARB_compute_shader - GL_ARB_conditional_render_inverted - GL_ARB_conservative_depth - GL_ARB_copy_buffer - GL_ARB_copy_image - GL_ARB_cull_distance - GL_ARB_debug_output - GL_ARB_depth_buffer_float - GL_ARB_depth_clamp - GL_ARB_depth_texture - GL_ARB_derivative_control - GL_ARB_direct_state_access - GL_ARB_draw_buffers - GL_ARB_draw_buffers_blend - GL_ARB_draw_elements_base_vertex - GL_ARB_draw_indirect - GL_ARB_draw_instanced - GL_ARB_enhanced_layouts - GL_ARB_explicit_attrib_location - GL_ARB_explicit_uniform_location - GL_ARB_fragment_coord_conventions - GL_ARB_fragment_layer_viewport - GL_ARB_fragment_program - GL_ARB_fragment_program_shadow - GL_ARB_fragment_shader - GL_ARB_framebuffer_no_attachments - GL_ARB_framebuffer_object - GL_ARB_framebuffer_sRGB - GL_ARB_geometry_shader4 - GL_ARB_get_program_binary - GL_ARB_get_texture_sub_image - GL_ARB_gl_spirv - GL_ARB_gpu_shader5 - GL_ARB_gpu_shader_fp64 - GL_ARB_half_float_pixel - GL_ARB_half_float_vertex - GL_ARB_imaging - GL_ARB_indirect_parameters - GL_ARB_instanced_arrays - GL_ARB_internalformat_query - GL_ARB_internalformat_query2 - GL_ARB_invalidate_subdata - GL_ARB_map_buffer_alignment - GL_ARB_map_buffer_range - GL_ARB_multi_bind - GL_ARB_multi_draw_indirect - GL_ARB_multisample - GL_ARB_multitexture - GL_ARB_occlusion_query - GL_ARB_occlusion_query2 - GL_ARB_parallel_shader_compile - GL_ARB_pipeline_statistics_query - GL_ARB_pixel_buffer_object - GL_ARB_point_parameters - GL_ARB_point_sprite - GL_ARB_polygon_offset_clamp - GL_ARB_program_interface_query - GL_ARB_provoking_vertex - GL_ARB_query_buffer_object - GL_ARB_robust_buffer_access_behavior - GL_ARB_sample_shading - GL_ARB_sampler_objects - GL_ARB_seamless_cube_map - GL_ARB_seamless_cubemap_per_texture - GL_ARB_separate_shader_objects - GL_ARB_shader_atomic_counters - GL_ARB_shader_ballot - GL_ARB_shader_bit_encoding - GL_ARB_shader_draw_parameters - GL_ARB_shader_group_vote - GL_ARB_shader_image_load_store - GL_ARB_shader_image_size - GL_ARB_shader_objects - GL_ARB_shader_precision - GL_ARB_shader_stencil_export - GL_ARB_shader_storage_buffer_object - GL_ARB_shader_subroutine - GL_ARB_shader_texture_image_samples - GL_ARB_shader_texture_lod - GL_ARB_shader_viewport_layer_array - GL_ARB_shading_language_100 - GL_ARB_shading_language_420pack - GL_ARB_shading_language_packing - GL_ARB_shadow - GL_ARB_shadow_ambient - GL_ARB_sparse_buffer - GL_ARB_sparse_texture - GL_ARB_spirv_extensions - GL_ARB_stencil_texturing - GL_ARB_sync - GL_ARB_tessellation_shader - GL_ARB_texture_barrier - GL_ARB_texture_border_clamp - GL_ARB_texture_buffer_object - GL_ARB_texture_buffer_object_rgb32 - GL_ARB_texture_buffer_range - GL_ARB_texture_compression - GL_ARB_texture_compression_bptc - GL_ARB_texture_compression_rgtc - GL_ARB_texture_cube_map - GL_ARB_texture_cube_map_array - GL_ARB_texture_env_add - GL_ARB_texture_env_combine - GL_ARB_texture_env_crossbar - GL_ARB_texture_env_dot3 - GL_ARB_texture_float - GL_ARB_texture_gather - GL_ARB_texture_mirror_clamp_to_edge - GL_ARB_texture_mirrored_repeat - GL_ARB_texture_multisample - GL_ARB_texture_non_power_of_two - GL_ARB_texture_query_levels - GL_ARB_texture_query_lod - GL_ARB_texture_rectangle - GL_ARB_texture_rg - GL_ARB_texture_rgb10_a2ui - GL_ARB_texture_snorm - GL_ARB_texture_stencil8 - GL_ARB_texture_storage - GL_ARB_texture_storage_multisample - GL_ARB_texture_swizzle - GL_ARB_texture_view - GL_ARB_timer_query - GL_ARB_transform_feedback2 - GL_ARB_transform_feedback3 - GL_ARB_transform_feedback_instanced - GL_ARB_transform_feedback_overflow_query - GL_ARB_transpose_matrix - GL_ARB_uniform_buffer_object - GL_ARB_vertex_array_bgra - GL_ARB_vertex_array_object - GL_ARB_vertex_attrib_64bit - GL_ARB_vertex_attrib_binding - GL_ARB_vertex_buffer_object - GL_ARB_vertex_program - GL_ARB_vertex_shader - GL_ARB_vertex_type_10f_11f_11f_rev - GL_ARB_vertex_type_2_10_10_10_rev - GL_ARB_viewport_array - GL_ARB_window_pos - GL_ATI_draw_buffers - GL_ATI_envmap_bumpmap - GL_ATI_fragment_shader - GL_ATI_separate_stencil - GL_ATI_texture_compression_3dc - GL_ATI_texture_env_combine3 - GL_ATI_texture_float - GL_ATI_texture_mirror_once - GL_EXT_abgr - GL_EXT_bgra - GL_EXT_bindable_uniform - GL_EXT_blend_color - GL_EXT_blend_equation_separate - GL_EXT_blend_func_separate - GL_EXT_blend_minmax - GL_EXT_blend_subtract - GL_EXT_compiled_vertex_array - GL_EXT_copy_buffer - GL_EXT_copy_texture - GL_EXT_depth_bounds_test - GL_EXT_direct_state_access - GL_EXT_draw_buffers2 - GL_EXT_draw_instanced - GL_EXT_draw_range_elements - GL_EXT_fog_coord - GL_EXT_framebuffer_blit - GL_EXT_framebuffer_multisample - GL_EXT_framebuffer_object - GL_EXT_framebuffer_sRGB - GL_EXT_geometry_shader4 - GL_EXT_gpu_program_parameters - GL_EXT_gpu_shader4 - GL_EXT_histogram - GL_EXT_memory_object - GL_EXT_memory_object_win32 - GL_EXT_multi_draw_arrays - GL_EXT_packed_depth_stencil - GL_EXT_packed_float - GL_EXT_packed_pixels - GL_EXT_pixel_buffer_object - GL_EXT_point_parameters - GL_EXT_polygon_offset_clamp - GL_EXT_provoking_vertex - GL_EXT_rescale_normal - GL_EXT_secondary_color - GL_EXT_semaphore - GL_EXT_semaphore_win32 - GL_EXT_separate_specular_color - GL_EXT_shader_image_load_store - GL_EXT_shader_integer_mix - GL_EXT_shadow_funcs - GL_EXT_stencil_wrap - GL_EXT_subtexture - GL_EXT_texgen_reflection - GL_EXT_texture3D - GL_EXT_texture_array - GL_EXT_texture_buffer_object - GL_EXT_texture_compression_bptc - GL_EXT_texture_compression_latc - GL_EXT_texture_compression_rgtc - GL_EXT_texture_compression_s3tc - GL_EXT_texture_cube_map - GL_EXT_texture_edge_clamp - GL_EXT_texture_env_add - GL_EXT_texture_env_combine - GL_EXT_texture_env_dot3 - GL_EXT_texture_filter_anisotropic - GL_EXT_texture_integer - GL_EXT_texture_lod - GL_EXT_texture_lod_bias - GL_EXT_texture_mirror_clamp - GL_EXT_texture_object - GL_EXT_texture_rectangle - GL_EXT_texture_sRGB - GL_EXT_texture_sRGB_R8 - GL_EXT_texture_sRGB_RG8 - GL_EXT_texture_sRGB_decode - GL_EXT_texture_shared_exponent - GL_EXT_texture_snorm - GL_EXT_texture_storage - GL_EXT_texture_swizzle - GL_EXT_timer_query - GL_EXT_transform_feedback - GL_EXT_vertex_array - GL_EXT_vertex_array_bgra - GL_EXT_vertex_attrib_64bit - GL_IBM_texture_mirrored_repeat - GL_INTEL_fragment_shader_ordering - GL_KHR_context_flush_control - GL_KHR_debug - GL_KHR_no_error - GL_KHR_parallel_shader_compile - GL_KHR_robust_buffer_access_behavior - GL_KHR_robustness - GL_KTX_buffer_region - GL_NV_alpha_to_coverage_dither_control - GL_NV_blend_square - GL_NV_conditional_render - GL_NV_copy_depth_to_color - GL_NV_copy_image - GL_NV_depth_buffer_float - GL_NV_explicit_multisample - GL_NV_float_buffer - GL_NV_half_float - GL_NV_primitive_restart - GL_NV_texgen_reflection - GL_NV_texture_barrier - GL_OES_EGL_image - GL_SGIS_generate_mipmap - GL_SGIS_texture_edge_clamp - GL_SGIS_texture_lod - GL_SUN_multi_draw_arrays - GL_WIN_swap_hint - WGL_EXT_swap_control - WGL_ARB_extensions_string - WGL_ARB_pixel_format - WGL_ATI_pixel_format_float - WGL_ARB_pixel_format_float - WGL_ARB_multisample - WGL_EXT_swap_control_tear - WGL_ARB_pbuffer - WGL_ARB_render_texture - WGL_ARB_make_current_read - WGL_EXT_extensions_string - WGL_ARB_buffer_region - WGL_EXT_framebuffer_sRGB - WGL_ATI_render_texture_rectangle - WGL_EXT_pixel_format_packed_float - WGL_I3D_genlock - WGL_NV_swap_group - WGL_ARB_create_context - WGL_AMD_gpu_association - WGL_ARB_create_context_profile - WGL_ARB_context_flush_control - WGL_NV_DX_interop - WGL_ARB_create_context_no_error - WGL_NV_DX_interop2 - OpenGL SPIR-V Extensions: 17 - SPV_AMD_shader_explicit_vertex_parameter - SPV_AMD_shader_trinary_minmax - SPV_AMD_gcn_shader - SPV_ARB_shader_ballot - SPV_ARB_shader_ballot - SPV_AMD_gpu_shader_half_float - SPV_ARB_shader_draw_parameters - SPV_ARB_shader_group_vote - SPV_AMD_texture_gather_bias_lod - SPV_ARB_shader_storage_buffer_object - SPV_AMD_gpu_shader_int16 - SPV_ARB_post_depth_coverage - SPV_ARB_shader_atomic_counter_ops - SPV_ARB_shader_stencil_export - SPV_AMD_shader_stencil_export - SPV_AMD_vertex_shader_viewport_index - SPV_ARB_shader_image_load_store
Vulkan support
This new version of Adrenalin brings the support of Vulkan 1.1.119.
Here is the complete report from GPU Caps Viewer for a Radeon RX Vega 56:
- Instance extensions: 11
- VK_KHR_surface (version: 25)
- VK_KHR_win32_surface (version: 6)
- VK_KHR_get_physical_device_properties2 (version: 1)
- VK_KHR_get_surface_capabilities2 (version: 1)
- VK_KHR_external_memory_capabilities (version: 1)
- VK_KHR_device_group_creation (version: 1)
- VK_KHR_external_semaphore_capabilities (version: 1)
- VK_KHR_external_fence_capabilities (version: 1)
- VK_EXT_debug_report (version: 9)
- VK_EXT_debug_utils (version: 1)
- VK_EXT_swapchain_colorspace (version: 4)
- Instance layers: 14
- VK_LAYER_AMD_switchable_graphics (version: 1.1.119, impl: 1)
- VK_LAYER_LUNARG_api_dump (version: 1.1.106, impl: 2)
- VK_LAYER_LUNARG_assistant_layer (version: 1.1.106, impl: 1)
- VK_LAYER_LUNARG_core_validation (version: 1.1.106, impl: 1)
- VK_LAYER_LUNARG_device_simulation (version: 1.1.106, impl: 1)
- VK_LAYER_KHRONOS_validation (version: 1.1.106, impl: 1)
- VK_LAYER_LUNARG_monitor (version: 1.1.106, impl: 1)
- VK_LAYER_LUNARG_object_tracker (version: 1.1.106, impl: 1)
- VK_LAYER_LUNARG_screenshot (version: 1.1.106, impl: 1)
- VK_LAYER_LUNARG_standard_validation (version: 1.1.106, impl: 1)
- VK_LAYER_LUNARG_parameter_validation (version: 1.1.106, impl: 1)
- VK_LAYER_GOOGLE_threading (version: 1.1.106, impl: 1)
- VK_LAYER_GOOGLE_unique_objects (version: 1.1.106, impl: 1)
- VK_LAYER_LUNARG_vktrace (version: 1.1.106, impl: 1)
- Physical devices: 2
- [Vulkan device 0]: Radeon RX Vega
- API version: 1.1.119
- vendorID: 4098
- deviceID: 26751
- driver version: 8388714
- memory heap count: 3
- heap1: 7920MB
- heap2: 7865MB
- heap3: 256MB
- memory type count: 8
- mem type 0 - heap index : 0 - property flag : 1
> mem property: VK_MEMORY_PROPERTY_DEVICE_LOCAL_BIT
- mem type 1 - heap index : 1 - property flag : 6
> mem property: VK_MEMORY_PROPERTY_HOST_VISIBLE_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_COHERENT_BIT
- mem type 2 - heap index : 2 - property flag : 7
> mem property: VK_MEMORY_PROPERTY_DEVICE_LOCAL_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_VISIBLE_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_COHERENT_BIT
- mem type 3 - heap index : 1 - property flag : 14
> mem property: VK_MEMORY_PROPERTY_HOST_VISIBLE_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_COHERENT_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_CACHED_BIT
- mem type 4 - heap index : 0 - property flag : 193
> mem property: VK_MEMORY_PROPERTY_DEVICE_LOCAL_BIT
- mem type 5 - heap index : 1 - property flag : 198
> mem property: VK_MEMORY_PROPERTY_HOST_VISIBLE_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_COHERENT_BIT
- mem type 6 - heap index : 2 - property flag : 199
> mem property: VK_MEMORY_PROPERTY_DEVICE_LOCAL_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_VISIBLE_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_COHERENT_BIT
- mem type 7 - heap index : 1 - property flag : 206
> mem property: VK_MEMORY_PROPERTY_HOST_VISIBLE_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_COHERENT_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_CACHED_BIT
- extensions: 88
- VK_KHR_sampler_mirror_clamp_to_edge (version: 1)
- VK_KHR_shader_draw_parameters (version: 1)
- VK_KHR_swapchain (version: 70)
- VK_KHR_maintenance1 (version: 2)
- VK_KHR_maintenance2 (version: 1)
- VK_KHR_maintenance3 (version: 1)
- VK_KHR_relaxed_block_layout (version: 1)
- VK_KHR_dedicated_allocation (version: 3)
- VK_KHR_descriptor_update_template (version: 1)
- VK_KHR_external_memory (version: 1)
- VK_KHR_external_memory_win32 (version: 1)
- VK_KHR_device_group (version: 3)
- VK_AMD_calibrated_timestamps (version: 1)
- VK_KHR_bind_memory2 (version: 1)
- VK_KHR_external_semaphore (version: 1)
- VK_KHR_external_semaphore_win32 (version: 1)
- VK_AMD_rasterization_order (version: 1)
- VK_AMD_shader_ballot (version: 1)
- VK_AMD_shader_core_properties2 (version: 1)
- VK_AMD_shader_trinary_minmax (version: 1)
- VK_AMD_shader_explicit_vertex_parameter (version: 1)
- VK_AMD_gcn_shader (version: 1)
- VK_AMD_draw_indirect_count (version: 1)
- VK_KHR_draw_indirect_count (version: 1)
- VK_AMD_negative_viewport_height (version: 1)
- VK_AMD_gpu_shader_half_float (version: 2)
- VK_AMD_shader_info (version: 1)
- VK_EXT_sampler_filter_minmax (version: 1)
- VK_AMD_shader_fragment_mask (version: 1)
- VK_EXT_hdr_metadata (version: 1)
- VK_AMD_wave_limits (version: 1)
- VK_AMD_texture_gather_bias_lod (version: 1)
- VK_AMD_mixed_attachment_samples (version: 1)
- VK_EXT_sample_locations (version: 1)
- VK_AMD_gpu_shader_int16 (version: 2)
- VK_EXT_shader_subgroup_vote (version: 1)
- VK_KHR_16bit_storage (version: 1)
- VK_KHR_storage_buffer_storage_class (version: 1)
- VK_AMD_gpa_interface (version: 1)
- VK_KHR_depth_stencil_resolve (version: 1)
- VK_EXT_shader_subgroup_ballot (version: 1)
- VK_EXT_shader_stencil_export (version: 1)
- VK_EXT_shader_viewport_index_layer (version: 1)
- VK_KHR_get_memory_requirements2 (version: 1)
- VK_KHR_image_format_list (version: 1)
- VK_KHR_swapchain_mutable_format (version: 1)
- VK_EXT_inline_uniform_block (version: 1)
- VK_KHR_shader_atomic_int64 (version: 1)
- VK_KHR_driver_properties (version: 1)
- VK_KHR_create_renderpass2 (version: 1)
- VK_KHR_8bit_storage (version: 1)
- VK_KHR_multiview (version: 1)
- VK_KHR_shader_float16_int8 (version: 1)
- VK_KHR_external_fence (version: 1)
- VK_KHR_external_fence_win32 (version: 1)
- VK_KHR_win32_keyed_mutex (version: 1)
- VK_EXT_global_priority (version: 2)
- VK_AMD_buffer_marker (version: 1)
- VK_AMD_shader_image_load_store_lod (version: 1)
- VK_EXT_external_memory_host (version: 1)
- VK_EXT_depth_clip_enable (version: 1)
- VK_EXT_depth_range_unrestricted (version: 1)
- VK_AMD_shader_core_properties (version: 1)
- VK_EXT_queue_family_foreign (version: 1)
- VK_EXT_descriptor_indexing (version: 2)
- VK_KHR_variable_pointers (version: 1)
- VK_EXT_vertex_attribute_divisor (version: 3)
- VK_EXT_conservative_rasterization (version: 1)
- VK_AMD_pipeline_compiler_control (version: 1)
- VK_GOOGLE_hlsl_functionality1 (version: 1)
- VK_GOOGLE_decorate_string (version: 1)
- VK_EXT_scalar_block_layout (version: 1)
- VK_AMD_memory_overallocation_behavior (version: 1)
- VK_EXT_transform_feedback (version: 1)
- VK_EXT_separate_stencil_usage (version: 1)
- VK_KHR_vulkan_memory_model (version: 3)
- VK_EXT_memory_priority (version: 1)
- VK_AMD_display_native_hdr (version: 1)
- VK_EXT_full_screen_exclusive (version: 3)
- VK_AMD_device_coherent_memory (version: 1)
- VK_EXT_memory_budget (version: 1)
- VK_EXT_host_query_reset (version: 1)
- VK_EXT_shader_demote_to_helper_invocation (version: 1)
- VK_EXT_line_rasterization (version: 1)
- VK_KHR_uniform_buffer_standard_layout (version: 1)
- VK_EXT_subgroup_size_control (version: 2)
- VK_KHR_imageless_framebuffer (version: 1)
- VK_EXT_calibrated_timestamps (version: 1)
- device layers: 1
- VK_LAYER_AMD_switchable_graphics (version: 1.1.119, impl: 1)
- device features:
- robustBufferAccess: true
- fullDrawIndexUint32: true
- imageCubeArray: true
- independentBlend: true
- geometryShader: true
- tessellationShader: true
- sampleRateShading: true
- dualSrcBlend: true
- logicOp: true
- multiDrawIndirect: true
- drawIndirectFirstInstance: true
- depthClamp: true
- depthBiasClamp: true
- fillModeNonSolid: true
- depthBounds: true
- wideLines: true
- largePoints: true
- alphaToOne: false
- multiViewport: true
- samplerAnisotropy: true
- textureCompressionETC2: false
- textureCompressionASTC_LDR: false
- textureCompressionBC: true
- occlusionQueryPrecise: true
- pipelineStatisticsQuery: true
- vertexPipelineStoresAndAtomics: true
- fragmentStoresAndAtomics: true
- shaderTessellationAndGeometryPointSize: true
- shaderImageGatherExtended: true
- shaderStorageImageExtendedFormats: true
- shaderStorageImageMultisample: true
- shaderStorageImageReadWithoutFormat: true
- shaderStorageImageWriteWithoutFormat: true
- shaderUniformBufferArrayDynamicIndexing: true
- shaderSampledImageArrayDynamicIndexing: true
- shaderStorageBufferArrayDynamicIndexing: true
- shaderStorageImageArrayDynamicIndexing: true
- shaderClipDistance: true
- shaderCullDistance: true
- shaderFloat64: true
- shaderInt64: true
- shaderInt16: true
- shaderResourceResidency: true
- shaderResourceMinLod: true
- sparseBinding: true
- sparseResidencyBuffer: true
- sparseResidencyImage2D: true
- sparseResidencyImage3D: true
- sparseResidency2Samples: false
- sparseResidency4Samples: true
- sparseResidency8Samples: false
- sparseResidency16Samples: false
- sparseResidencyAliased: true
- variableMultisampleRate: true
- inheritedQueries: true
- device limits
- maxImageDimension1D: 16384
- maxImageDimension2D: 16384
- maxImageDimension3D: 2048
- maxImageDimensionCube: 16384
- maxImageArrayLayers: 2048
- maxTexelBufferElements: 4294967295
- maxUniformBufferRange: 4294967295
- maxStorageBufferRange: 4294967295
- maxPushConstantsSize: 128
- maxMemoryAllocationCount: 4096
- maxSamplerAllocationCount: 1048576
- bufferImageGranularity: 1
- sparseAddressSpaceSize: 17579301142528
- maxBoundDescriptorSets: 32
- maxPerStageDescriptorSamplers: 4294967295
- maxPerStageDescriptorUniformBuffers: 4294967295
- maxPerStageDescriptorSampledImages: 4294967295
- maxPerStageDescriptorStorageImages: 4294967295
- maxPerStageDescriptorInputAttachments: 4294967295
- maxPerStageResources: 4294967295
- maxDescriptorSetSamplers: 4294967295
- maxDescriptorSetUniformBuffers: 4294967295
- maxDescriptorSetUniformBuffersDynamic: 8
- maxDescriptorSetStorageBuffers: 4294967295
- maxDescriptorSetStorageBuffersDynamic: 8
- maxDescriptorSetSampledImages: 4294967295
- maxDescriptorSetStorageImages: 4294967295
- maxDescriptorSetInputAttachments: 4294967295
- maxVertexInputAttributes: 64
- maxVertexInputBindings: 32
- maxVertexInputAttributeOffset: 4294967295
- maxVertexInputBindingStride: 16383
- maxVertexOutputComponents: 128
- maxTessellationGenerationLevel: 64
- maxTessellationPatchSize: 32
- maxTessellationControlPerVertexInputComponents: 128
- maxTessellationControlPerVertexOutputComponents: 128
- maxTessellationControlPerPatchOutputComponents: 120
- maxTessellationControlTotalOutputComponents: 4096
- maxTessellationEvaluationInputComponents: 128
- maxTessellationEvaluationOutputComponents: 128
- maxGeometryShaderInvocations: 127
- maxGeometryInputComponents: 128
- maxGeometryOutputComponents: 128
- maxGeometryOutputVertices: 1024
- maxGeometryTotalOutputComponents: 16384
- maxFragmentInputComponents: 128
- maxFragmentOutputAttachments: 8
- maxFragmentDualSrcAttachments: 1
- maxFragmentCombinedOutputResources: 4294967295
- maxComputeSharedMemorySize: 32768
- maxComputeWorkGroupCount: [65535; 65535; 65535]
- maxComputeWorkGroupInvocations: 1024
- maxComputeWorkGroupSize: [1024; 1024; 1024]
- subPixelPrecisionBits: 8
- subTexelPrecisionBits: 8
- mipmapPrecisionBits: 8
- maxDrawIndexedIndexValue: 4294967295
- maxDrawIndirectCount: 4294967295
- maxSamplerLodBias: 15.996094
- maxSamplerAnisotropy: 16.000000
- maxViewports: 16
- maxViewportDimensions: [16384; 16384]
- viewportBoundsRange: [-32768.000000 ; 32767.000000]
- viewportSubPixelBits: 8
- minMemoryMapAlignment: 64
- minTexelBufferOffsetAlignment: 4
- minUniformBufferOffsetAlignment: 16
- minStorageBufferOffsetAlignment: 4
- minTexelOffset: 4294967232
- maxTexelOffset: 63
- minTexelGatherOffset: 4294967264
- maxTexelGatherOffset: 31
- minInterpolationOffset: -2.000000
- maxInterpolationOffset: 2.000000
- subPixelInterpolationOffsetBits: 8
- maxFramebufferWidth: 16384
- maxFramebufferHeight: 16384
- maxFramebufferLayers: 2048
- framebufferColorSampleCounts: 15
- framebufferDepthSampleCounts: 15
- framebufferStencilSampleCounts: 15
- framebufferNoAttachmentsSampleCounts: 15
- maxColorAttachments: 8
- sampledImageColorSampleCounts: 15
- sampledImageIntegerSampleCounts: 15
- sampledImageDepthSampleCounts: 15
- sampledImageStencilSampleCounts: 15
- storageImageSampleCounts: 15
- maxSampleMaskWords: 1
- timestampComputeAndGraphics: 1
- timestampPeriod: 37.037037
- maxClipDistances: 8
- maxCullDistances: 8
- maxCombinedClipAndCullDistances: 8
- discreteQueuePriorities: 2
- pointSizeRange: [0.000000 ; 8191.875000]
- lineWidthRange: [0.000000 ; 8191.875000]
- pointSizeGranularity: 0.125000
- lineWidthGranularity: 0.125000
- strictLines: 0
- standardSampleLocations: 1
- optimalBufferCopyOffsetAlignment: 1
- optimalBufferCopyRowPitchAlignment: 1
- nonCoherentAtomSize: 128
- [Vulkan device 1]: Intel(R) UHD Graphics 630
- API version: 1.1.103
- vendorID: 32902
- deviceID: 16018
- driver version: 1645311
- memory heap count: 2
- heap1: 3610340565007MB
- heap2: 3610340565007MB
- memory type count: 3
- mem type 0 - heap index : 0 - property flag : 1
> mem property: VK_MEMORY_PROPERTY_DEVICE_LOCAL_BIT
- mem type 1 - heap index : 1 - property flag : 7
> mem property: VK_MEMORY_PROPERTY_DEVICE_LOCAL_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_VISIBLE_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_COHERENT_BIT
- mem type 2 - heap index : 1 - property flag : 15
> mem property: VK_MEMORY_PROPERTY_DEVICE_LOCAL_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_VISIBLE_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_COHERENT_BIT
> mem property: VK_MEMORY_PROPERTY_HOST_CACHED_BIT
- extensions: 48
- VK_KHR_swapchain (version: 68)
- VK_KHR_external_memory (version: 1)
- VK_KHR_external_memory_win32 (version: 1)
- VK_EXT_external_memory_host (version: 1)
- VK_KHR_external_semaphore (version: 1)
- VK_KHR_external_semaphore_win32 (version: 1)
- VK_KHR_external_fence (version: 1)
- VK_KHR_external_fence_win32 (version: 1)
- VK_KHR_get_memory_requirements2 (version: 1)
- VK_KHR_bind_memory2 (version: 1)
- VK_KHR_dedicated_allocation (version: 1)
- VK_KHR_sampler_mirror_clamp_to_edge (version: 1)
- VK_KHR_maintenance1 (version: 1)
- VK_KHR_maintenance2 (version: 1)
- VK_KHR_maintenance3 (version: 1)
- VK_KHR_shader_draw_parameters (version: 1)
- VK_KHR_push_descriptor (version: 1)
- VK_KHR_descriptor_update_template (version: 1)
- VK_KHR_multiview (version: 1)
- VK_KHR_shader_float16_int8 (version: 1)
- VK_KHR_16bit_storage (version: 1)
- VK_KHR_8bit_storage (version: 1)
- VK_EXT_shader_subgroup_ballot (version: 1)
- VK_EXT_shader_subgroup_vote (version: 1)
- VK_KHR_storage_buffer_storage_class (version: 1)
- VK_KHR_variable_pointers (version: 1)
- VK_KHR_relaxed_block_layout (version: 1)
- VK_EXT_sampler_filter_minmax (version: 1)
- VK_KHR_device_group (version: 1)
- VK_KHR_sampler_ycbcr_conversion (version: 1)
- VK_EXT_post_depth_coverage (version: 1)
- VK_EXT_shader_viewport_index_layer (version: 1)
- VK_EXT_shader_stencil_export (version: 1)
- VK_EXT_conservative_rasterization (version: 1)
- VK_EXT_sample_locations (version: 1)
- VK_KHR_draw_indirect_count (version: 1)
- VK_KHR_image_format_list (version: 1)
- VK_EXT_vertex_attribute_divisor (version: 3)
- VK_EXT_descriptor_indexing (version: 2)
- VK_EXT_inline_uniform_block (version: 1)
- VK_KHR_create_renderpass2 (version: 1)
- VK_KHR_swapchain_mutable_format (version: 1)
- VK_KHR_driver_properties (version: 1)
- VK_KHR_vulkan_memory_model (version: 3)
- VK_EXT_conditional_rendering (version: 1)
- VK_EXT_depth_clip_enable (version: 1)
- VK_EXT_scalar_block_layout (version: 1)
- VK_EXT_host_query_reset (version: 1)
- device layers: 1
- VK_LAYER_AMD_switchable_graphics (version: 1.1.119, impl: 1)
- device features:
- robustBufferAccess: true
- fullDrawIndexUint32: true
- imageCubeArray: true
- independentBlend: true
- geometryShader: true
- tessellationShader: true
- sampleRateShading: true
- dualSrcBlend: true
- logicOp: true
- multiDrawIndirect: true
- drawIndirectFirstInstance: true
- depthClamp: true
- depthBiasClamp: true
- fillModeNonSolid: true
- depthBounds: false
- wideLines: true
- largePoints: true
- alphaToOne: true
- multiViewport: true
- samplerAnisotropy: true
- textureCompressionETC2: true
- textureCompressionASTC_LDR: true
- textureCompressionBC: true
- occlusionQueryPrecise: true
- pipelineStatisticsQuery: true
- vertexPipelineStoresAndAtomics: true
- fragmentStoresAndAtomics: true
- shaderTessellationAndGeometryPointSize: true
- shaderImageGatherExtended: true
- shaderStorageImageExtendedFormats: true
- shaderStorageImageMultisample: true
- shaderStorageImageReadWithoutFormat: false
- shaderStorageImageWriteWithoutFormat: true
- shaderUniformBufferArrayDynamicIndexing: true
- shaderSampledImageArrayDynamicIndexing: true
- shaderStorageBufferArrayDynamicIndexing: true
- shaderStorageImageArrayDynamicIndexing: true
- shaderClipDistance: true
- shaderCullDistance: true
- shaderFloat64: true
- shaderInt64: true
- shaderInt16: true
- shaderResourceResidency: true
- shaderResourceMinLod: false
- sparseBinding: true
- sparseResidencyBuffer: true
- sparseResidencyImage2D: true
- sparseResidencyImage3D: true
- sparseResidency2Samples: true
- sparseResidency4Samples: true
- sparseResidency8Samples: true
- sparseResidency16Samples: true
- sparseResidencyAliased: true
- variableMultisampleRate: true
- inheritedQueries: true
- device limits
- maxImageDimension1D: 16384
- maxImageDimension2D: 16384
- maxImageDimension3D: 2048
- maxImageDimensionCube: 16384
- maxImageArrayLayers: 2048
- maxTexelBufferElements: 134217728
- maxUniformBufferRange: 65536
- maxStorageBufferRange: 134217728
- maxPushConstantsSize: 256
- maxMemoryAllocationCount: 574627742
- maxSamplerAllocationCount: 4000
- bufferImageGranularity: 1
- sparseAddressSpaceSize: 17592186044416
- maxBoundDescriptorSets: 8
- maxPerStageDescriptorSamplers: 64
- maxPerStageDescriptorUniformBuffers: 200
- maxPerStageDescriptorSampledImages: 200
- maxPerStageDescriptorStorageImages: 16
- maxPerStageDescriptorInputAttachments: 8
- maxPerStageResources: 200
- maxDescriptorSetSamplers: 512
- maxDescriptorSetUniformBuffers: 1600
- maxDescriptorSetUniformBuffersDynamic: 16
- maxDescriptorSetStorageBuffers: 1600
- maxDescriptorSetStorageBuffersDynamic: 16
- maxDescriptorSetSampledImages: 1600
- maxDescriptorSetStorageImages: 128
- maxDescriptorSetInputAttachments: 8
- maxVertexInputAttributes: 32
- maxVertexInputBindings: 32
- maxVertexInputAttributeOffset: 2047
- maxVertexInputBindingStride: 4095
- maxVertexOutputComponents: 128
- maxTessellationGenerationLevel: 64
- maxTessellationPatchSize: 32
- maxTessellationControlPerVertexInputComponents: 128
- maxTessellationControlPerVertexOutputComponents: 128
- maxTessellationControlPerPatchOutputComponents: 120
- maxTessellationControlTotalOutputComponents: 4096
- maxTessellationEvaluationInputComponents: 128
- maxTessellationEvaluationOutputComponents: 128
- maxGeometryShaderInvocations: 32
- maxGeometryInputComponents: 128
- maxGeometryOutputComponents: 128
- maxGeometryOutputVertices: 256
- maxGeometryTotalOutputComponents: 1024
- maxFragmentInputComponents: 128
- maxFragmentOutputAttachments: 8
- maxFragmentDualSrcAttachments: 1
- maxFragmentCombinedOutputResources: 16
- maxComputeSharedMemorySize: 32768
- maxComputeWorkGroupCount: [65536; 65536; 65536]
- maxComputeWorkGroupInvocations: 1024
- maxComputeWorkGroupSize: [1024; 1024; 64]
- subPixelPrecisionBits: 8
- subTexelPrecisionBits: 8
- mipmapPrecisionBits: 8
- maxDrawIndexedIndexValue: 4294967295
- maxDrawIndirectCount: 4294967295
- maxSamplerLodBias: 16.000000
- maxSamplerAnisotropy: 16.000000
- maxViewports: 16
- maxViewportDimensions: [32768; 32768]
- viewportBoundsRange: [-65536.000000 ; 65535.000000]
- viewportSubPixelBits: 8
- minMemoryMapAlignment: 64
- minTexelBufferOffsetAlignment: 16
- minUniformBufferOffsetAlignment: 32
- minStorageBufferOffsetAlignment: 16
- minTexelOffset: 4294967288
- maxTexelOffset: 7
- minTexelGatherOffset: 4294967264
- maxTexelGatherOffset: 31
- minInterpolationOffset: -0.500000
- maxInterpolationOffset: 0.437500
- subPixelInterpolationOffsetBits: 4
- maxFramebufferWidth: 16384
- maxFramebufferHeight: 16384
- maxFramebufferLayers: 2048
- framebufferColorSampleCounts: 31
- framebufferDepthSampleCounts: 31
- framebufferStencilSampleCounts: 31
- framebufferNoAttachmentsSampleCounts: 31
- maxColorAttachments: 8
- sampledImageColorSampleCounts: 31
- sampledImageIntegerSampleCounts: 31
- sampledImageDepthSampleCounts: 31
- sampledImageStencilSampleCounts: 31
- storageImageSampleCounts: 31
- maxSampleMaskWords: 1
- timestampComputeAndGraphics: 1
- timestampPeriod: 83.333000
- maxClipDistances: 8
- maxCullDistances: 8
- maxCombinedClipAndCullDistances: 8
- discreteQueuePriorities: 2
- pointSizeRange: [0.125000 ; 255.875000]
- lineWidthRange: [0.000000 ; 7.992188]
- pointSizeGranularity: 0.125000
- lineWidthGranularity: 0.007813
- strictLines: 0
- standardSampleLocations: 1
- optimalBufferCopyOffsetAlignment: 16
- optimalBufferCopyRowPitchAlignment: 16
- nonCoherentAtomSize: 1
