[TessMark] OpenGL 4 Tessellation Benchmark: Comparative Table



TessMark PRO - OpenGL 4 tessellation benchmark



Now that Catalyst 10.8 drivers have fixed the Radeon HD 58xx tessellation bug, I can publish comparative tables for TessMark, the OpenGL 4 tessellation benchmark. The following results are valid with the 0.2.x branch of TessMark. Use these results as a quick way to rank your graphics card regarding the GPU tessellation.

This post will be regularly updated.


1 – Geeks3D Results

Testbed:
- CPU: Core i7 960 @ 3.2GHz
- RAM: 4GB DDR3 Corsair Dominator
- Motherboard: GIGABYTE X58-A UD5
- Windows 7 64-bit
- R258.96 + Cat 10.8
- PSU: Corsair AX1200
- All graphics cards have been tested with default clocks.



TessMark settings:
- 1920×1080 fullscreen
- no AA, no Post-FX
- duration=60sec
- map set 1



Tessellation: moderate

97804 (1632FPS) – GeForce GTX 480 3-way SLI (R258.96)
81631 (1364FPS) – GeForce GTX 480 2-way SLI (R258.96)
48084 (804FPS) – EVGA GeForce GTX 480 (R258.96)
30512 (510FPS)MSI N460GTX Cyclone 768D5 OC (R258.96)
29232 (487FPS) – MSI R5770 Hawk CrossFire (Cat 10.8)
27000 (450FPS) – ATI Radeon HD 5870 (Cat 10.8)
20366 (340FPS)MSI R5770 Hawk (Cat 10.8)
5185 – Mobility Radeon HD 5470 (Cat 10.7)



Tessellation: normal

69952 (1167FPS) – GeForce GTX 480 3-way SLI (R258.96)
52648 (879FPS) – GeForce GTX 480 2-way SLI (R258.96)
29196 (487FPS) – EVGA GeForce GTX 480 (R258.96)
17452 (291FPS) – MSI N460GTX Cyclone 768D5 OC (R258.96)
13667 (228FPS) – MSI R5770 Hawk CrossFire (Cat 10.8)
8177 (136FPS) – ATI Radeon HD 5870 (Cat 10.8)
7515 (125FPS) – MSI R5770 Hawk (Cat 10.8)
2349 – Mobility Radeon HD 5470 (Cat 10.7)



Tessellation: extreme

34934 (583FPS) – GeForce GTX 480 3-way SLI (R258.96)
24837 (414FPS) – GeForce GTX 480 2-way SLI (R258.96)
13008 (217FPS) – EVGA GeForce GTX 480 (R258.96)
6729 (112FPS) – MSI N460GTX Cyclone 768D5 OC (R258.96)
4094 (68FPS) – MSI R5770 Hawk CrossFire (Cat 10.8)
2150 (36FPS) – ATI Radeon HD 5870 (Cat 10.8)
2114 (35FPS) – MSI R5770 Hawk (Cat 10.8)
820 – Mobility Radeon HD 5470 (Cat 10.7)



Tessellation: insane

7810 (130FPS) – GeForce GTX 480 2-way SLI (R258.96)
3963 (66FPS) – EVGA GeForce GTX 480 (R258.96)
1959 (33FPS) – MSI N460GTX Cyclone 768D5 OC (R258.96)
1028 (18FPS) – MSI R5770 Hawk CrossFire (Cat 10.8)
551 (10FPS) – MSI R5770 Hawk (Cat 10.8)
548 (10FPS) – ATI Radeon HD 5870 (Cat 10.8)
234 – Mobility Radeon HD 5470 (Cat 10.7)



2 – Results from around the Web

Tessellation: normal – 1024×768 fullscreen

65391 (1091FPS) – GeForce GTX 480 2-way SLI, 0X MSAA, (GPU core=700MHz, GPU mem=1848MHz, CPU=Intel Core i7 X980 @ 3.33GHz, source)
42400 (707FPS) – GeForce GTX 460 2-way SLI, 0X MSAA, (GPU core=860MHz, GPU mem=2100MHz, CPU=Intel Core 2 Duo E6750 @ 2.66GHz, source: Arctucas)
27910 (466FPS) – GeForce GTX 470, 0X MSAA, (GPU core=655MHz, GPU mem=1125MHz, CPU=AMD Phenom II X4 940, source)
24985 (416FPS) – GeForce GTX 460, 0X MSAA, (GPU core=920MHz, GPU mem=2200MHz, CPU=Intel Core Q9650 @ 3GHz, source)
18922 (315FPS) – GeForce GTX 460, 0X MSAA, (GPU core=675MHz, GPU mem=1800MHz, CPU=Intel Core Q9650 @ 3GHz, source)
9081 (151FPS) – Radeon HD 5870 (Cat 10.7a), 0X MSAA, (GPU core=900MHz, GPU mem=1250MHz, CPU=Intel Core Q9550 @ 2.83GHz, source)
8679 (145FPS) – Radeon HD 5870 (Cat 10.7a), 8X MSAA, (GPU core=900MHz, GPU mem=1250MHz, CPU=Intel Core Q9550 @ 2.83GHz, source)



Tessellation: extreme – 1024×768 fullscreen

15917 (265FPS) – GeForce GTX 460 2-way SLI, 0X MSAA, (GPU core=860MHz, GPU mem=2100MHz, CPU=Intel Core 2 Duo E6750 @ 2.66GHz, source: Arctucas)
10786 (180FPS) – GeForce GTX 470, 0X MSAA, (GPU core=655MHz, GPU mem=1125MHz, CPU=AMD Phenom II X4 940, source)
8787 (146FPS) – GeForce GTX 460, 0X MSAA, (GPU core=920MHz, GPU mem=2200MHz, CPU=Intel Core Q9650 @ 3GHz, source)
6518 (109FPS) – GeForce GTX 460, 0X MSAA, (GPU core=675MHz, GPU mem=1800MHz, CPU=Intel Core Q9650 @ 3GHz, source)
2300 (39FPS) – Radeon HD 5870 (Cat 10.7a), 0X MSAA, (GPU core=900MHz, GPU mem=1250MHz, CPU=Intel Core Q9550 @ 2.83GHz, source)



Tessellation: insane – 1024×768 fullscreen

8011 (133FPS) – GeForce GTX 480 2-way SLI, 0X MSAA, (GPU core=700MHz, GPU mem=1848MHz, CPU=Intel Core i7 X980 @ 3.33GHz, source)
4591 (77FPS) – GeForce GTX 460 2-way SLI, 0X MSAA, (GPU core=860MHz, GPU mem=2100MHz, CPU=Intel Core 2 Duo E6750 @ 2.66GHz, source: Arctucas)
2475 (41FPS) – GeForce GTX 460, 0X MSAA, (GPU core=920MHz, GPU mem=2200MHz, CPU=Intel Core Q9650 @ 3GHz, source)
1821 (31FPS) – GeForce GTX 460, 0X MSAA, (GPU core=675MHz, GPU mem=1800MHz, CPU=Intel Core Q9650 @ 3GHz, source)
580 (10FPS) – Radeon HD 5870 (Cat 10.7a), 0X MSAA, (GPU core=900MHz, GPU mem=1250MHz, CPU=Intel Core Q9550 @ 2.83GHz, source)



Tessellation: normal – 1680×1050 fullscreen

39135 (653FPS) – GeForce GTX 460, 0X MSAA (GPU core=880MHz, GPU mem=2125MHz, CPU=Core i5 750 @ 2.67GHz, source)
34705 (579FPS) – GeForce GTX 480, 0X MSAA (GPU core=843MHz, GPU mem=1980MHz, CPU=Core i7 920 @ 2.67GHz, source)
9678 (161FPS) – Radeon HD 5850 (Cat 10.8), 0X MSAA, (GPU core=1000MHz, GPU mem=1250MHz, CPU=AMD Phenom II X6 1090T, source)
8476 (141FPS) – Radeon HD 5850 (Cat 10.8), 0X MSAA, (GPU core=900MHz, GPU mem=1200MHz, CPU=Core i5 750 @ 2.67GHz, source)



Tessellation: insane – 1680×1050 fullscreen

3595 (60FPS) – GeForce GTX 470, 4X MSAA (GPU core=780MHz, GPU mem=1750MHz, CPU=Core i5 750 @ 2.67GHz, source)
3171 (60FPS) – GeForce GTX 470, 4X MSAA (GPU core=607MHz, GPU mem=1674MHz, CPU=Core 2 Quad Q9400 @ 2.66GHz, source)
319 (6FPS) – Radeon HD 5500 Series, 0X MSAA (GPU core=550MHz, GPU mem=400MHz, CPU=Pentium Dual Core E5300 @ 2.60GHz, source)



Tessellation: extreme – 1920×1080 fullscreen

22074 (368FPS) – GeForce GTX 470, 0X MSAA, (GPU core=700MHz, GPU mem=1700MHz, CPU=Core i7 920 @ 2.67GHz, source)
915 (16FPS) – Radeon HD 5970, 8X MSAA, (GPU core=725MHz, GPU mem=1000MHz, CPU=AMD Phenom II X4 955, source)



Tessellation: insane – 1920×1080 fullscreen

5469 (91FPS) – GeForce GTX 470, 16X MSAA, (GPU core=830MHz, GPU mem=1800MHz, CPU=Core i5 750 @ 2.67GHz, source)
1876 (32FPS) – GeForce GTX 460, 0X MSAA, (GPU core=700MHz, GPU mem=1800MHz, CPU=Intel Quad core Q9550 @ 2.83GHz, source: Psolord)
915 (16FPS) – Radeon HD 5970, 8X MSAA, (GPU core=725MHz, GPU mem=1000MHz, CPU=AMD Phenom II X4 955, source)
466 (8FPS) – Radeon HD 5850 (Cat 10.8), 0X MSAA, (GPU core=725MHz, GPU mem=1000MHz, CPU=Intel Core i7 860 @ 2.80GHz, source: Psolord)



Tessellation: normal – 1920×1200 fullscreen

35637 (595FPS) – GeForce GTX 460, 0X MSAA (GPU core=880MHz, GPU mem=2125MHz, CPU=Core i5 750 @ 2.67GHz, source)
26641 (445FPS) – GeForce GTX 480, 0X MSAA (GPU core=700MHz, GPU mem=1848MHz, CPU=Core i7 960 @ 3.20GHz, source)
9507 (158FPS) – Radeon HD 5850 (Cat 10.8), 0X MSAA, (GPU core=1000MHz, GPU mem=1250MHz, CPU=AMD Phenom II X6 1090T, source)
8634 (144FPS) – Radeon HD 5870 (Cat 10.7a), 0X MSAA, (GPU core=900MHz, GPU mem=1250MHz, CPU=Intel Core Q9550 @ 2.83GHz, source)
7740 (129FPS) – Radeon HD 5870 (Cat 10.7a), 8X MSAA, (GPU core=900MHz, GPU mem=1250MHz, CPU=Intel Core Q9550 @ 2.83GHz, source)



Tessellation: insane – 1920×1200 fullscreen

7740 (129FPS) – Radeon HD 5870 (Cat 10.7a), 8X MSAA, (GPU core=900MHz, GPU mem=1250MHz, CPU=Intel Core Q9550 @ 2.83GHz, source)
5781 (97FPS) – GeForce GTX 480, 16X MSAA, (GPU core=860MHz, GPU mem=1999MHz, CPU=Intel Core i7 X980 @ 3.33GHz, source)
590 (10FPS) – Radeon HD 5850, 0X MSAA, (GPU core=920MHz, GPU mem=1260MHz, CPU=Intel Core i7 860 @ 2.80GHz, source: jpriton)
